SOT-23 Std Tape and Reel Data
SOT23-3L Packaging
Configuration: F igure 1.0
Cus tomized Lab el
Antis tatic Cover Tape
Packaging Description:
S OT 23-3L par ts ar e s hipped i n tape. T he carrier tape is
made from a d issipative (carbon filled) polycarbonate
resin. T he cover tape i s a m ultilay er film (Heat Activated
Adhes ive in nature) primarily c omposed o f polyester film,
adhes ive l ayer, seal ant, and anti-static s prayed ag ent.
T hes e reeled parts i n s tandard option ar e s hipped with
3, 000 units per 7 " or 177mm diameter reel. T he r eels ar e
dark blue in c olor and is made of polystyrene plas tic ( anti-
static coated). O ther option c omes in 10,000 units per 13"
or 330c m diameter reel. T his and s ome other options ar e
des cribed in the P ackaging I nformation table.
T hes e f ull reel s are i ndividually labeled and plac ed inside
a s tandar d immediate bo x made o f recyclable corrugated
brown paper w ith a F airchild logo p rinting. One box
contains five reel s maximum. And thes e immediate boxes
are plac ed inside a labeled s hipping box which c omes i n
F63TNR Lab el
E mbosse d
Carri er Tape
different s izes depending on the number of parts s hipped.
3P
3P
3P
3P
SOT23-3L Packaging Information
Packaging Option
Packaging type
Qty per Reel/Tube/Bag
Reel Size
Box Dimension (mm)
Max qty per Box
Weight per unit (gm)
Weight per Reel (kg)
S tandar d
(no flow code)
TN R
3, 000
7" Dia
193x 183x80
15, 000
0. 0082
0. 1175
D87Z
TN R
10, 000
13"
355x 333x40
30, 000
0. 0082
0. 4006
SOT23-3L Unit Orientation
B arcode L abel
Note/Comments
B arcode
355m m x 333m m x 40m m
Intermediate c ontainer f or 13" re el option
Lab el
B arcode L abel s ample
LO T : CB V K 741B 019
F S ID: MMS Z5221B
D/C1: D9842AB QT Y 1: SPEC REV:
D/C2: QT Y 2: CP N:
QT Y : 3000
SPEC :
B arcode
Lab el
F AIRCHI LD S E MIC ONDUCT OR C ORP OR AT ION
(F 63T NR)
193m m x 183m m x 80m m
P izza B ox for S tandard O ption
SOT23-3L Tape Leader and Trailer
Configuration: F igure 2.0
C arrier Tape
C over T ape
Tr ailer Ta pe
C omponents
Leade r T ape
300mm minimum or
75 em pty pock ets
?2001 Fairchild Semiconductor Corporation
? 2010 Fairchild Semiconductor Corporation
BS170 / MMBF170 Rev. E2
11
500mm minimum or
125 em pty pockets
October 2004, Rev. D1
